- Van điều khiển Bardiani BBZK
- Model: Bardiani BBZK
- Hãng: Bardiani
Connections from DN25 to DN100
Gskets: EPDM, FKM, HNBR and PTFE
Maximum pressure 10 bar-
Bảng giá sản phẩm
Số lượng Giá bán (VNĐ) 0+ Liên hệ Thông tin đặt hàngTối thiểu: 1Đặt hàng
- Mô tả chi tiết
- Thông số kỹ thuật
- Bình luận
MODULATING VALVE WITH MEMBRANE ACTUATOR
ATEX
3A 53-06MAIN BENEFIT/USP
Maximum regulation reliability- Flexibility thanks to the numerous options and variations available
- Optimization of process efficiency
- Serviceable actuator
DESCRIPTION
BBZK is a modulating valve designed to regulate the flow rate and maintain a constant level, pressure or temperature value. Its special membrane actuator connected to the positioner allows partial opening and closing of the shutter, allowing intermediate flow rates and consequently pressure drop in the valve. Particularly suitable for applications where accurate control of the pressure, temperature and level measurements in the filling tank are required.
STANDARD FEATURES
- Connections from DN25 to DN100 (from 1” to 4”)
- EPDM, FKM, HNBR and PTFE gaskets
- Maximum pressure 10 bar
DOWNLOAD
-
BBZK MANUAL-1220-I
-
BBZK MANUAL-1220-EN
-
BBZK MANUAL-1220-F
-
BBZK MANUAL-1220-E
-
BBZK MANUAL-1220-D
-
BBZK MANUAL-1220-RUS
-
BBZK BBZPM Catalogue IT/EN 1120
-
Regulation valves configuration form
-
SIEMENS instruction manual IT
-
SIEMENS instruction manual EN
-
SIEMENS instruction manual FR
-
SIEMENS instruction manual ES
-
SIEMENS instruction manual DE
-
Servocomando pneumatico / Pneumatic power control
-
BBZK DWG TrueView
-
BBZK Autodesk Inventor View
